VHF / UHF RADIO COMMUNICATION


SAILOR 7222 VHF DSC Class A Product description

  • The SAILOR 7222 VHF DSC Class A is the most advanced SAILOR radio
    for demanding users operating within the SOLAS maritime environment.

  • Exceeding standards set by IMO regulation for GMDSS Class A VHF, the
    August 2021 introduced Bridge Alert Management IMO resolution MSC.302(87),
    as well as IEC 62923-1 & IEC 62923-2, the SAILOR 7222 VHF DSC Class A
    is a robust platform for when clear communication could make the difference
    between a nonevent or a major incident.

  • The SAILOR 7222 VHF DSC Class A VHF is quick and easy to install
    standalone, or as a core component of a SAILOR GMDSS console.

  • Advanced networking functionality also significantly reduces the installation
    and service burden, when deployed as part of a fully compliant solution with
    other compatible SAILOR products, including mini-C, MF/HF, Navtex and AIS.
Product brochure

SAILOR 6248 VHF Product description

  • The SAILOR 6248 VHF is designed for all maritime work environments.
    In addition to the standard international maritime VHF channels, it also
    includes special channel tables for USA, Canada and BI (For inland Waterways)
    incl. ATIS and ATIS ‘killer’, and as standard up to 100 private channels (P/F/L).

  • It is suited for a wide variety of maritime operational communications aboard
    fishing vessels, workboats and merchant and offshore ships.

  • The SAILOR 6248 VHF is rated waterproof to both IPx6 and IPx8, making
    it possible to install on open workboats or outside deck areas.
Product brochure

SAILOR 6249 VHF Survival Craft Product description

  • The SAILOR 6249 VHF Survival Craft is designed specifically for
    installation aboard survival crafts. It includes the standard international
    maritime VHF channels as required in a Survival Craft VHF and as
    standard up to 100 private channels (P/F/L).

  • The SAILOR 6249 VHF Survival Craft is Wheelmark (MED-B) approved
    and complies with the ETSI EN 301 466 standard.

  • It is rated waterproof to both IPx6 and IPx8.
Product brochure

SAILOR 6210 VHF Product description

  • The SAILOR 6210 VHF is the first in a series of new SAILOR 6200 VHF.

  • Large easy-to-read display with red backlight and dimming.

  • High quality, powerful 6W loudspeaker.

  • Full waterproof to IPx8 (submersible) and IPx6 (spray) all over.

  • ATIS facility for inland waterways.
Product brochure

SIMRAD RS20S VHF DSC Class D Product description

  • The SIMRAD RS20S is VHF DSC Class D approved marine radio with
    integrated GPS receiver. Ideal for a variety of boats from small RIBs to larger
    cruisers, and is designed to match the low-profile style of modern Simrad
    Glass Bridge displays and accessories.

  • Key Features:
    - High visibility LCD with inverted night mode
    - Intuitive rotary and keypad controls
    - Four-button fist microphone
    - Class D DSC Approved
    - Integrated GPS receiver
    - NMEA 2000® compatible
    - Dedicated emergency channel key
    - Tri-channel watch function
    - All international channels
    - Easy bracket or flush-mount installation

  • ATIS facility for inland waterways (EU mode).
Product brochure

SIMRAD RS40 VHF DSC Class D
AIS
Product description

  • The SIMRAD RS40 VHF radio offers Class D DSC functionality with built-in
    GPS receiver. Keep track of nearby AIS-equipped vessels with an integrated
    AIS receiver.

  • The SIMRAD RS40-B includes a Class B AIS transceiver, which not only
    receives AIS targets but also transmits your boat's position to nearby
    AIS-equipped vessels.

  • Key Features:
    - Class D DSC approved VHF radio
    - Dual Channel AIS Receiver
    - Integrated GPS receiver
    - Removable fist mic supports front or rear connection
    - Connect up to two wireless handsets
    - Add an optional loudhailer or external speaker
    - NMEA 0183® and NMEA 2000 connectivity

  • Up to two portable wireless HS40 handsets allow to make and receive radio
    calls from anywhere on the vessel within a range of up to 100m (direct line
    of sight, no obstructions). Intercom calls between handsets or radio base allow
    all units to keep in touch.

  • ATIS facility for inland waterways (EU mode).
Product brochure

SIMRAD RS100 VHF DSC Class D
AIS
Product description

  • The Simrad RS100 is a modular VHF system that’s expandable and
    customisable to suit any boat and any on-water communication needs.

  • The standard package includes one wired handset and one external speaker.
    This setup is expandable up to eight handsets (four wired and four wireless)
    and four external speakers - ideal for use as an on- board intercom with
    Simrad HS40 wireless or HS100 wired handsets.

  • The SIMRAD RS100-B includes a Class B AIS transceiver.

  • Key Features:
    - Class D DSC approved VHF radio
    - Class B AIS transceiver (RS100-B)
    - Integrated GPS receiver
    - Connect up to four wired and four wireless handsets
    - Add an optional loudhailer and up to four external speakers
    - NMEA 0183® and NMEA 2000 connectivity

  • ATIS facility for inland waterways (EU mode).

Product brochure

SAILOR SP3500 Portable VHF/UHF Product description
""
  • The SAILOR SP3500 portable series offers a following models for all marine
    applications, including GMDSS and ATEX versions. All versions are in a robust
    and waterproof design that ensures reliable communication even under the
    harsh conditions at sea.

  • International, US, Canadian and Inland (BI) Waterways channel with ATIS
    are selectable by the user and even more channels can easily be entered
    by the dealer.

  • For users who require a private conversation over the radios, the SAILOR
    SP3515, SAILOR SP3530 (ATEX), SAILOR SP3550 and SAILOR SP3560
    (ATEX) also offer scrambling features.

  • The SAILOR SP3500 Portable series all come with: Transceiver and antenna,
    Belt clip and lanyard, rechargeable battery and charger, AC/DC converter/
    adaptor and DC connection. In addition the SAILOR SP3520 and SAILOR
    SP3540 also includes a emergency battery for GMDSS application.
Product brochure

SAILOR 3965 UHF FIRE FIGHTER Product description

  • The SAILOR 3965 UHF Fire Fighter radio has been developed specifically
    for the fulfilment of the SOLAS requirement. Built on the legacy of SAILOR
    SP3500 series portable radios, the SAILOR 3965 UHF Fire Fighter radio
    provides reliable, feature rich communication that helps to make the fire party
    safe and effective when called into action.

  • The special red colour of the radio ensures that the dedicated purpose and
    use of the radio is not violated. As a special safety option the SAILOR 3965
    UHF Fire Fighter radio can be supplied with a non- rechargeable emergency
    battery providing the highest possible safety when deploying the fire party
    instantly.

  • For ships constructed on or after 1 July 2014, a minimum of two two- way
    portable radiotelephone apparatus for each fire party for fire- fighter´s
    communication shall be carried on board. Those two twoway radiotelephone
    apparatuses shall be of an explosion-proof type or intrinsically safe.
    Ships constructed before 1 July 2014 shall comply with the requirements
    of this paragraph not later than the first survey after 1 July 2018.

  • ATEX Approved Class II 2G Ex ib IIB T4.
Product brochure

ENTEL HT Series
- Portable VHF/UHF
Product description

  • Entel’s HT Commercial Marine portable radios are specifically designed to
    withstand the everyday rigours of the Maritime workplace.

  • Exceeding MIL-STD 810C/D/E/F rating, the HT Series 2.0 is designed to
    withstand shock, vibration, dust and moisture, ensuring a tough enduring
    performance and many years of trouble free use, even in the most hostile
    environments.

  • The HT649 GMDSS is MED certified and carries the essential Wheel Mark
    logo. For those requiring a, no compromise, fully featured GMDSS portable
    with high visibility back-lit LCD, the HT649 GMDSS will exceed the
    expectations of even the most experienced radio user.

Product brochure

ENTEL DX Series
- Portable VHF/UHF
Product description

  • Entel DX series offers outstanding performance in both DMR digital and
    analogue modes. This rugged handset delivers audio volume and clarity
    that’s unmatched by portables twice its size and the high contrast OLED
    display is complemented by the intuitive controls designed with gloved
    hands in mind.

  • The DX400M offers the highest submersibility rating of any manufacturer.
    It can withstand total immersion in water to a depth of 2 metres for 4 hours
    which protects against corrosion and other likely hazards encountered in
    maritime operations.

  • The DX400M delivers an impressive 2 watts of natural sounding digital audio,
    exceeding the output of radios twice it’s size. In addition, all of the DX range
    of accessories benefit from Entel’s proprietary “Smart Speech Tailoring”
    technology which automatically detects the type of accessory connected
    and optimizes the audio accordingly to deliver the very best performance.
Product brochure

ENTEL DX-IS Series
- Intrinsically Safe VHF/UHF
Product description

  • Available in either VHF or UHF, display and non-display models,
    the commercial grade DX-IS Series sets the benchmark for next generation
    onboard intrinsically safe portables.

  • Standard features include both analogue and digital modes of operation,
    high visibility OLED display, high torque ergonomic controls designed for
    gloved-hand use, and industry-leading IP68 2m 4 hours submersible rating,
    to provide excellent reliability and usability even in the most extreme conditions.

  • Approved and certified to UL913, for users who do not need to comply
    with the European ATEX directive.
Product brochure

ENTEL DTEx Series
- Intrinsically Safe VHF/UHF
Product description

  • Available in either VHF or UHF, display and non-display models,
    the commercial grade DX-IS Series sets the benchmark for next generation
    onboard intrinsically safe portables.

  • Standard features include both analogue and digital modes of operation,
    high visibility OLED display, high torque ergonomic controls designed for
    gloved-hand use, and industry-leading IP68 2m 4 hours submersible rating,
    to provide excellent reliability and usability even in the most extreme conditions.

  • Intrinsically Safe Approved:
    - ATEX Approved IIC - The DT900 Series of ATEX certified portables meet IIC
      gas group, the most stringent ATEX rating as per EU Directive 94/9/EC.
    - ATEX Approved IIB - The DT800 Series of ATEX certified portables meet IIB
      gas group.
    - IECEx Approval IIB - The DT500 range of intrinsically safe certified portables
      are suitablefor those users who do not need to comply with the European
      ATEX standard.
Product brochure

ENTEL DTEx Series
- Firefighter VHF/UHF
Product description

  • The industrial grade DTEx Fire Fighter Series is designed and approved to
    meet the latest MED standard implementation regulation MED/5.20 and
    European ATEX directive.

  • Available in both VHF and UHF models, the ultra durable fire-red coloured
    DTEx Series sets the benchmark for next-generation MED compliant
    Firefighter radios.

  • Standard features include both analogue and digital modes of operation,
    high visibility OLED display, high torque ergonomic controls designed for
    gloved-hand use, and industry-leading IP68 2m 4 hours submersible rating,
    to provide 100% reliability and usability even in the most extreme conditions.
Product brochure
